Lomanco Turbines Set TIB14 + Base + Extension 50 cm

This set is suitable on cases where the turbine must be placed above the surface of the roof to catch sufficient force wind power. The set consists of the most powerful Lomanco TIB 14" turbine, in the aluminium version, a 50 cm extension part and a square base. The base and extension are made of galvanized steel.

Lomanco Turbines Set TIB14 + Base + Extension 50 cm

Features & Benefits

  • 14" neck diameter
  • 14" turbine moves up to 37% more air than the 12"
  • All-aluminium rust-free turbine construction
  • Extension and base are made of galvanized steel
  • Easy installation
  • Lomanco turbine - Lifetime warranty

Dimensions

Calculating ventilation

Ventilated area Units needed
0-90 m2 2
> 90 m2 2
> 140 m2 2
> 185 m2 3
> 230 m2 3
Wind speed Exhausted air (m/3)
8 km/h 710 m³/h
13 km/h 1200 m³/h
24 km/h 2250 m³/h

Flat roof

Pitched image

In the box

  • Turbine TIB14
  • 14" extension part 50 cm
  • Square base
  • Screws
  • Installation Guide

Our tip

Set of turbine, a 50 cm extension part and a square base for easy installation.

Lifetime Warranty

All Lomanco products come with a Lifetime Warranty. The warranty is transferable from the original owner to subsequent owners and applies to residential use only. Commercial use is covered by a 15 year warranty. We provide a standard 2 year warranty on all the accessories.
